Front Terminal Kaise

OVERVIEW OF THE RANGE

The batteries in the Kaise Front Terminal series have been developed for applications that require high performance and easy maintenance. They are mainly used in the telecommunications sector, ensuring that, in the event of a power failure, they immediately supply the necessary energy, thus acting as a power backup for simple or more complex communication systems.

Description

High-density plates bonded with Pb-Sn-Ca alloy for longer battery life
Centralized degassing system
Plastic or rope handles for easy transportation and installation
Front terminals for easy connection
Low internal resistance
Low internal discharge
Design life up to 10-12 years
External and internal materials made of flame-retardant ABS plastics, V0 rated

Telecommunication systems
UPS equipment
Power stations

*To see the complete content, scroll horizontally*.

MODEL	TERMINAL TYPE	NOMINAL VOLTAGE V	RATED CAPACITY Ah	WEIGHT Kg	LENGTH mm	DEPTH mm	HEIGHT mm	TOTAL HEIGHT mm	DATASHEET
KBF121000	M6	12	100	31.0	394	110	286	286
KBF121050	M6	12	100	32.8	508	110	238.5	238.5
KBF121550	M8	12	150	44.8	551	110	288	288
KBF122000	M8	12	200	61.0	560	126	320	320
